Farmtrac 26 4WD

Farmtrac 26 4WD

power 24,7 HP

Farmtrac 26 4WD

  1. Power

    24,7 HP @ 2500 RPM

    Air filter

    dry

    NA/TC/TCI

    NA

    No. of cilinders

    3

  2. PTO speed- Std

    540/540E

    PTO RPM @ Engine RPM

    540 @ 2504 / 540E @ 2035

  3. Type

    Constant Mesh

    No. of Gears

    9 Forward + 3 Reverse

    Differential Lock

    yes

  4. Type

    Single Clutch

  5. 3-POINT LINKAGES

    CAT IN

  6. Functions

    Draft & Position Control

    Type & Lift Capacity (Kg)

    750 Kg (at hitch point)

    Auxiliary Valve, Rear

    1 Double Acting (2 nos.)

  7. Steering

    Power Steering

  8. Type

    Oil Immersed Brakes

    Hand Brake

    Independent

  9. Front Axle

    4WD

  10. Front Tyre

    6 x 12

    Rear Tyre

    8.3 x 20

  11. Lenght, mm

    min.: 2315 max.: 2677

    Width, mm

    min.: 1041 max.: 1413

    Height, mm

    min.: 1398 max.: 2192

    Wheelbase, mm

    1551

  12. Weight - unballasted (kg)

    min. 869 max: 879

  13. Fuel Tank capacity, ltrs. (+/-5%)

    24 L

  14. OTHER FEATURES

    Downdraft exhaust, battery Cut-off Switch, operator presence switch

    OPTIONAL FEATURES

    Industrial tyres: 23x8.50-12 & 33x15.5-16.5, turf tyres: 23x8.50-12 & 33x15.5-16.5, radial tyres: 180/85D12 & 280/70R18, Mounted Heater Cabin Mounted Heater Cabin Company Fitted Platform Cabin (Heater)
Find out more about this model
The Farmtrac 26 4WD is a compact tractor designed to be used in small agricultural, municipal, horticulture or just around the house - wherever dimension matters. The Farmtrac compact tractor is multitasking, versatile and reliable. Perfect for gardens, orchards, tunnels and shelters. They work perfectly with a flail mower with a basket, a plow, a sweeper, and a sand spreader. As standard, the tractor is equipped with a foldable ROPS frame, with the possibility of retrofitting a cabin or specialized wheels.
